Solid Wood Panels

Solid Wood Panels

Facts

Solid wood panels produced according to your dimensions.
Our solid wood panels are produced from selected wood, which is cut in the company´s own sawmill according to high qualitiy standards. The panels available in different wood types are especially used in individual interior construction (table tops, stair construction, cover boards,…).

DESIGN

Fully solid class AB/C and/or AB/AB, with continous lamella, glued butted together. Wood moisture 8-10 %, D3 glued. Surface sanded (K100), edge cut (edge processing against surcharge).

CLASSIFICATION OF THE COMPANY NOTHEGGER MASSIV:

A.

Sober, balanced, decorative appearance with approximately same colour, carefully selected. Virtually without features typical of wood types.

B.

Lively appearance, occasional features typical of wood types, sealed surface.

C.

Without special requirements for parts not visible. No sealed surface, cracks, knotholes and occasional incompletely dressed lamella.

Note: When installing solid wood panels, one should ensure that it is possible for the boards to expand and shrink, expecially in width. Wood is a living, hygroscopic material that reacts to carying air moisture.

BARS

In the case of solid wood boards, we generally recommend the use of bars, which take over the function of dovetail battens and allow swelling and shrinkage of the board with slotted hole screw joints, but prevent warping.

* Lamella width with 32 and 40 mm thickness, rising from 5-15 cm.

** Lamella width wiith 52 mm thickness, remains same at 42 mm.

BARS AND/OR DOVETAIL BATTENS

Example: If a solid wood board is attached to a metal frame, it must be ensure that the board can expand and shrink several millimetres by means of a slotted hole.

PANEL THICKNESSES

14 mm, 32 mm, 40 * mm, 52 ** mm

SURFACE

Untreated/raw

PANEL SIZES

Length max. 2500 mm
Width max. 1300 mm
Special sizes on inquiry

WOOD TYPES

Maple
KL. AB slightly bleached

Beech
KL. AB slightly steamed

Oak knotty
KL. B.

Ash
KL. AB

Oak knotless
KL. AB

Ash rustic
KL. B (olive) with core

Pine
KL. AB

Oak rustic
KL. BC / C cracks and knots puttied black
